Features
- Fast Recovery Rectifier
- Fast Recovery Times
- Soft Recovery Characteristics
- Flag Lead and Stud Top Terminals
- Available
- High Surge Current Ratings
- High Rated Blocking Voltages
- Special Electrical Selection for Parallel
- and Series Operation
- Glazed Ceramic Seal Gives
- High Voltage Creepage and Strike Paths
Aplications
- Applications
- Inverters
- Choppers
- Transmitters
- Free Wheeling Diode
Powerex Fast Recovery Diodes, R502/503 Series
Powerex
R5031213LSWS
Diode,DO-8L,1200V,125A,REV,700nS Black,Silicon Rubber Sleeve ; Polarity; Anode Stud (Reverse)
Vrrm (volts); 1200 Volts
IF (rms) Amps; 195 Amps
IF (avg) Amps; 125 Amps
Ifsm Amps; 2500 Amps
I2T@60Hz (A2Sec); 26000
Vfm (volts); 2.5 Volts
trr (nanoseconds); 700 NanoSeconds
Junction Temp.; 302 Degrees F
Mounting Force; 120 lbf-inches
Stud Size; 3/8-24 UNF-2A
Lead Type; Flexible Insulated Black
Lead Length FMS (inches); 6.32 Inches ;
R5031213LSWS
Riferimenti Specifici
- MPN
- R5031213LSWS
