C165N
69,30 $
steuerfrei
C165N
Política de seguridad
(Los productos cuentan con garantía limitada, por favor revisa nuestras condiciones)
Shipping and Returns
All products come with a warranty against manufacturing defects.
Trademark Disclaimer
All trademarks, logos, and part numbers are the property of their respective owners click for more
Features
SILICON CONTROLLED RECTIFIER
Aplications
Semiconductors High Power Equipment Repair
Powerex Inverter SCRs, C165 Series
Powerex
C165N
SCR, TO-94, 800V, 110A, TQ=20 ; Package Style; TO-94
Vrrm (volts); 800 Volts
Vdrm (volts); 800 Volts
It (rms) Amps; 110 Amps
Itsm Amps; 1800 Amps
dv/dt (V/microseconds); 500
(A2Sec); 13500
(A2Sec); 9500
Vtm (volts); 2.6 Volts
tq (microseconds); 10 MicroSeconds
Irrm Peak (mA); 12 MilliAmps
Idrm Peak (mA); 12 MilliAmps
Vgt (volts); 5 Volts
Stud Size; 1/2-20 UNF-2A
Lead Length FMS (inches); 6.39 Inches
Junction Temp.; 257 Degrees F
Mounting Force; 14~17Nm
C165N
Besondere Bestellnummern
- Hersteller-Teilenummer (MPN)
- C165N
