SKM200GB173D
144,38 $
steuerfrei
SKM200GB173D
Política de seguridad
(Los productos cuentan con garantía limitada, por favor revisa nuestras condiciones)
Política de entrega
(Envíos de 1-2 días hábiles para productos de stock)
Features
- IGBT MODULE
- MOS Input (voltage controlled)
- N channel, Homogeneous Si
- Low inductance case
- Very low tail current with low temperature dependence
- High short circuit capability, self limiting to 6 x Icnom
- Latch-up free
- Fast & soft inverse CAL diodes
- Isolated copper baseplate using DCB Direct Copper Bonding Technology
- Large clearance (13 mm) and creepage distance (20 mm)
Aplications
- Applications
- AC inverter drives on mains 575 - 750 V AC
- DC bus voltage 750 - 1200 V DC
- Public transport (auxiliary syst.)
- Switching (not for linear use)
Semikron IGBTs
Semikron
SKM200GB173D
IGBT 200A 1700V DUAL ; Type; Dual
Vces; 1700 Volts DC
Ic; 150 Amps
Vges +/-; 20
Ices Max; 0.3 MilliAmps
Vge(th) Min/Max; 4.8~6.2 Volts
Vce(sat) Max; 3.9 Volts
Height (mm); 30.5
Width (mm); 106.4
Depth (mm); 61.4
RoHS; Yes ;
SKM200GB173D
Besondere Bestellnummern
- Hersteller-Teilenummer (MPN)
- SKM200GB173D
