SKM75GAR063D
93,19 $
steuerfrei
SKM75GAR063D
Política de seguridad
(Los productos cuentan con garantía limitada, por favor revisa nuestras condiciones)
Shipping and Returns
All products come with a warranty against manufacturing defects.
Trademark Disclaimer
All trademarks, logos, and part numbers are the property of their respective owners click for more
Features
Super NPT-IGBT Module
N channel, homogeneous Si-structure (NPT-Non punch-through IGBT)
Low tail current with low temperature dependence
High short circuit capability, self limiting if term. G is clamped to E
Pos. Temp.-coeff. Of VCEsat
Very low Cies, Coes, Cres
Latch-up free
Fast & soft inverse CAL diodes
Isolated copper baseplate using DBC Direct Copper Bonding Technology without hard mould
Large clearance (10 mm) and creepage distances (20 mm)
Aplications
Applications
Switching (not for linear use)
Switched mode power supplies
Three phase inverters for servo / AC motor speed control
Pulse frequencies also > 10 kHz
Semikron IGBTs
Semikron
SKM75GAR063D
IGBT 75A 600V HIGH CHOPPER ; Type; Single
Vces; 600 Volts DC
Ic; 75 Amps
Vges +/-; 20
Ices Max; 0.3 MilliAmps
Vge(th) Min/Max; 4.5~6.5 Volts
Vce(sat) Max; 2.5 Volts
Height (mm); 30.5
Width (mm); 94
Depth (mm); 34
RoHS; Yes ;
SKM75GAR063D
Besondere Bestellnummern
- Hersteller-Teilenummer (MPN)
- SKM75GAR063D
