- On request
CD430890B
47,25 $
steuerfrei
MODULOS THYRISTOR THYRISTOR
Última actualización
CD430890B90A/800V/2U
No Identificado
Delivery time :
Política de seguridad
(Los productos cuentan con garantía limitada, por favor revisa nuestras condiciones)
Shipping and Returns
All products come with a warranty against manufacturing defects.
Trademark Disclaimer
All trademarks, logos, and part numbers are the property of their respective owners click for more
Features
Dual SCR Isolated Module
Electrically Isolated Heatsinking
DBC Alumina (AI2-O3) Insulator
Copper Baseplate
Low Thermal Impedance for Improved
Current Capability
UL Recognized (E78240)
Aplications
Applications
Bridge Circuits
AC & DC Motor Drives
Battery Supplies
Power Supplies
Large IGBT Circuit Front Ends
Lighting Control
Heat & Temperature Control
Welders
Powerex Standard SCR Power Modules, CD Series
Powerex
CD430890B
PMOD, DUAL-SCR, 800V, 90A ; It (avg); 95 Amps
It (RMS); 150 Amps
Vrrm; 800 Volts
Circuit; SCR Doubler w/aux Cathode
Height (mm) Nominal; 30 MilliMeters
Width (mm) Nominal; 20 MilliMeters
Depth (mm) Nominal; 93 MilliMeters
Igt; 150 MilliAmps
di/dt (Amps/MicroSec.); 150
dV/dt (Volts/MicroSec.); 500
Aux. Cathode(s); Yes
Mounting Centers; 80 MilliMeters
Approvals; ULR
RoHS; Yes ;
CD430890B
Besondere Bestellnummern
- Hersteller-Teilenummer (MPN)
- CD430890B
