- Nicht auf Lager
2N1804
51,98 $
steuerfrei
2N1804
Política de seguridad
(Los productos cuentan con garantía limitada, por favor revisa nuestras condiciones)
Política de entrega
(Envíos de 1-2 días hábiles para productos de stock)
Features
- Power Integrated module (PIM)
- NPT-Technology
- Solderable Package
- Square SC SOA at 10 x Ic
- High Short Circuit Withstand-Capability
- Small Temperature Dependance of the Turn-Off
- Switching Loss
- Low Losses And Soft Switching
Aplications
- Semiconductors High Power Equipment Repair
Powerex Phase Control SCRs, 2N Series
Powerex
2N1804
SCR, TO-83, 1000V, 70A ; Package Style; TO-83
Vrrm (volts); 1000 Volts
Vdrm (volts); 1000 Volts
It (rms) Amps; 110 Amps
It (avg) Amps; 70 Amps
Itsm Amps; 1000 Amps
dv/dt (V/microseconds); 300
I2T@60Hz (A2Sec); 4000
Vtm (volts); 2.3 Volts
tq (microseconds); 100 MicroSeconds
Igt (mA); 70 MilliAmps
Vgt (volts); 3 Volts
Stud Size; 1/2-20 UNF-2A
Lead Length FMS (inches); 7.04 Inches
Junction Temp.; -40~257 Degrees F
Mounting Force; 130 lbf-inches
2N1804
Besondere Bestellnummern
- Hersteller-Teilenummer (MPN)
- 2N1804
