- Nicht auf Lager
CR6L-150
42,00 $
steuerfrei
CR6L-150
Política de seguridad
(Los productos cuentan con garantía limitada, por favor revisa nuestras condiciones)
Política de entrega
(Envíos de 1-2 días hábiles para productos de stock)
Features
- Super Rapid Fuses
- 150-1500 volts AC
- 10-4700 Amps
- The total clearing I2t is small and the semiconductor circuit
- is completely protected
- Since the peak arc voltage at the time of interruption is low
- damage to other equipment does not occur
- High interrupting capacity of 200kA of 1000V AC
Aplications
- Semiconductors High Power Equipment Repair
Fuji Japanese Fuses, CR Series
Fuji
CR6L-150
FUSE, 150A, 600VAC, SEMI, FOOTED I2T=18000, W/O INDICATOR 95mm OAL X 30mm DIA X 70mm C-C ; Amps; 150
Volts AC; 600
Volts DC; 680
Characteristic; Semiconductor
Package Type; Offset Bolted
Interrupt Rating; 100kA @ 600V
I2t Clearing Amps; 18000 Amps
Length (mm); 95 MilliMeters
Width (mm); 25 MilliMeters
Depth (mm); 34 MilliMeters
Diameter (mm); 25 MilliMeters
Mounting Centers (mm); 70 MilliMeters ;
CR6L-150
Besondere Bestellnummern
- Hersteller-Teilenummer (MPN)
- CR6L-150
