- Nicht auf Lager
SP721AP
10,74 $
steuerfrei
SP721AP
Política de seguridad
(Los productos cuentan con garantía limitada, por favor revisa nuestras condiciones)
Política de entrega
(Envíos de 1-2 días hábiles para productos de stock)
Features
- Electronic Protection Array for ESD and Overvoltage Protection
- ESD Interface Capability for HBM Standars
- MIL STD 3015.7u00e2u0080u00a6u00e2u0080u00a6u00e2u0080u00a6.15kV
- IEC 61000-4-2, Direct Discharge,
- Single Input u00e2u0080u00a6u00e2u0080u00a6u00e2u0080u00a6..4kV (Level 2)
- Two Inputs in Parallel u00e2u0080u00a6u00e2u0080u00a6..8kV (Level 4)
- IEC 61000-4-2, Air Discharge ..........15kV (Level 4)
- High Peak Current Capability
- IEC 61000-4-5 (8/20us)........+-3A
- Single Pulse, 100us Pulse width ......+-2A
- Single Pulse, 4us Pulse Width ..........+-5A
- Designed to Provide Over-Voltage Protection
- Single-Ended Voltage Range to ............+30V
- Differential Voltage Range to ...............+-15V
- Fast Switching ............. 2ns Rise Time
- Low Input Leakages ......1nA at 25u00c2u00b0C Typical
- Low Input Capacitance ....... 3pF Typical
- An Array of 6 SCR/Diode Pairs
- Operating Temperature Range .......-40u00c2u00b0C to 105u00c2u00b0C
Aplications
- Applications
- Microprocessor/Logic Input
- Protection
- Data Bus Protection
- Analog Device Input Protection
- Voltage Clamp
SP721AP
Besondere Bestellnummern
- Hersteller-Teilenummer (MPN)
- SP721AP
