T358N18TOF

Infineon Phase Control SCRs, T358N Series

Infineon

T358N18TOF

SCR,TO41/14,1800V,358A ; Package Style; TO-200AB-1

Vrrm (volts); 1800 Volts

Vdrm (volts); 1800 Volts

It (rms) Amps; 700 Amps

It (avg) Amps; 358 Amps

Itsm Amps; 5200 Amps

di/dt (A/microseconds); 150

dv/dt (V/microseconds); 1000

(A2Sec); 135000

Vtm (volts); 2.07 Volts

tq (microseconds); 250 MicroSeconds

Irrm Peak (mA); 50 MilliAmps

Idrm Peak (mA); 50 MilliAmps

Igt (mA); 200 MilliAmps

Vgt (volts); 2 Volts

Puck Size (h x dia.) in.; .5x1.63

Junction Temp.; 257 Degrees F

Mounting Force; 5 kN

RoHS; Yes

Diag. No.; EUPC_SCR_DIAG_T41.14_23POLE
