400UR120D
search
  • 400UR120D
  • 400UR120D

400UR120D

$48.51
No tax

DIODO DE RECUPERACION

Última actualización

Datasheet400UR120D

400A/1200V/1U

No identificado

Delivery time :

Quantity
Out-of-Stock

  Política de seguridad

(Our products have limited warranty, please check our terms)

  Política de entrega

(Delivery 1-2 days for products in stock)

Features

  • STu00c3u0081NDAR RECOVERY DIODES
  • Wide current range
  • High surge current capabilities
  • Stud cathode and stud anode version
  • Estu00c3u00a1ndar JEDEC types

Aplications

  • Applications
  • Converters
  • Power supplies
  • Machine tool controls
  • High power drives

Vishay Standard Recovery Diodes, 400U Series

Vishay

400UR120D

Diode,DO-9L,1200V,400A,Rev,Std ; Package Type; DO-205AB (DO-9)

Polarity; Anode Stud (Reverse)

Vrrm (volts); 1200 Volts

IF (rms) Amps; 630 Amps

IF (avg) Amps; 400 Amps

Ifsm Amps; 8640 Amps

I2T@60Hz (A2Sec); 311000

I2T@50Hz (A2Sec); 340000

Vfm (volts); 1.62 Volts

Junction Temp.; -40~392 Degrees F

Mounting Force; 238 lbf-inches

Stud Size; 3/4-16 UNF-2A

Lead Type; Flexible

Lead Length FMS (inches); 7.87 Inches

RoHS Compliant; Yes ;

400UR120D

Specific References

MPN
400UR120D
