PM100RLA120
$530.25
No tax
PM100RLA120
Política de seguridad
(Our products have limited warranty, please check our terms)
Shipping and Returns
All products come with a warranty against manufacturing defects.
Trademark Disclaimer
All trademarks, logos, and part numbers are the property of their respective owners click for more
Features
INTELLIGENT POWER MODULE
Adopting new 4th generation planar IGBT (CSTBT) chip, which performance is improved by 1um fine rule process. For example, typical VCE(sat)=1.9V @ Tj = 125u00c2u00b0C
I adopt the over-temperature conservation by Tj detection of CSTBT chip, and error output is possible from all each conservation upper and lower arm of IPM
Current rating of brake part increased
50% for the current rating of inverter part
3 phase 100A, 1200V Current-sense IGBT type inverter
50A, 1200V Current-sense regenerative brake IGBT
Monolithic gate drive & protection logic
Detection, protection & status indication circuits for over-current, short-circuit, over-temperature &
under-voltage (P-Fo available from upper arm devices)
Acoustic noise-less 18.5kW/22kW class inverter application
UL Recognized Yellow Card No. E80276(N)
File No. E80271
Aplications
Applications
General purpose Inverter
Servo drives
Motor control
PM100RLA120
Specific References
- MPN
- PM100RLA120
