PM150RLB060

INTELLIGENT POWER MODULE

Adopting new 5th generation IGBT (CSTBT) chip, which performance is improved by 1um fine rule process. For example, typical VCE(sat)=1.9V @ Tj = 125u00c2u00b0C

I adopt the over-temperature conservation by Tj detection of CSTBT chip, and error output is possible from all each conservation upper and lower arm of IPM

Current rating of brake part increased

50% for the current rating of inverter part

3 phase 150A, 1200V Current-sense IGBT type inverter

Monolithic gate drive & protection logic

Detection, protection & status indication circuits for over-current, short-circuit, over-temperature &

under-voltage (P-Fo available from upper arm devices)

Acoustic noise-less 30kW class inverter application

UL Recognized Yellow Card No. E80276(N)

File No. E80271

Applications

General purpose Inverter

Servo drives

Motor control
