- On request
PM75CBS060
$310.50
No tax
IGBT - IPM
Última actualización
PM75CBS06075A/600V/6U
MITSUBISHI
Delivery time : 1-2 semanas.
Política de seguridad
(Our products have limited warranty, please check our terms)
Shipping and Returns
All products come with a warranty against manufacturing defects.
Trademark Disclaimer
All trademarks, logos, and part numbers are the property of their respective owners click for more
Features
INTELLIGENT POWER MODULE
Adopting 4TH generation IGBT chip, which performance is improved by 1um fine rule process
For example, typical Vce8sat) = 1.7V
Using new Diode which is designed to get soft reverse recovery characteristics
Over-temperature protection by detecting Tj of the IGBT chips
3 phase 75A, 600V Current-sense IGBT type inverter
Monolithic gate drive & protection logic
Detection, protection & status indication circuits
for, short-circuit, over-temperature & under-voltage
Acoustic noise-less 5.5/7.5kW class inverter application
Aplications
Applications
servo drives
motor controls
