LD421650

$323.98
No tax

MODULO THYRISTOR DIODO

Última actualización

DatasheetLD421650

500A/1600V/2U

No identificado

Delivery time :

Quantity
Out-of-Stock

  Política de seguridad

(Our products have limited warranty, please check our terms)

  Política de entrega

(Delivery 1-2 days for products in stock)

Features

  • Dual SCR/Diode MODULE
  • Electrically Isolated Heatsinking
  • Aluminum Nitride Insulator
  • Compression Bonded Elements
  • Metal Baseplate
  • Low Thermal Impedance for improved
  • Current Capability
  • Quick Connected Gate Terminal with
  • Provision for Keyed Mating Plug
  • UL Recognized

Aplications

  • Applications
  • Bridge Circuits
  • AC & DC Motor Drives
  • Battery Supplies
  • Power Supplies
  • Large IGBT Circuit Front Ends

Powerex Hybrid SCR-Diode Power Modules, LD Series

Powerex

LD421650

Power Module 500A 1600V SCR-Diode Less Terminal Hardware or Aux Gate Leads ; It (avg); 500 Amps

It (RMS); 785 Amps

Vrrm; 1600 Volts

Circuit; Diode-SCR w/aux Cathode

Height (mm) Nominal; 52 MilliMeters

Width (mm) Nominal; 60 MilliMeters

Depth (mm) Nominal; 150 MilliMeters

Igt; 200 MilliAmps

di/dt (Amps/MicroSec.); 200

dV/dt (Volts/MicroSec.); 1000

Aux. Cathode(s); Yes

Mounting Centers; 112 MilliMeters

Approvals; ULR

RoHS; Yes ;

LD421650

Specific References

MPN
LD421650
