- Out-of-Stock
SKN320/08
$86.63
No tax
SKN320/08
Política de seguridad
(Our products have limited warranty, please check our terms)
Política de entrega
(Delivery 1-2 days for products in stock)
Features
- Rectifier Diode
- Reverse voltage up to 1600 V
- Hermetic metal cases with glass insulators
- Threaded studs ISO M24 x 1.5
- SKN : anode to stud
- SKR : cathode to stud
Aplications
- Applications
- All-purpose mean power rectifier diodes
- Cooling via heatsinks
- Non-controllable and
- half-controllable rectifiers
- Free-wheeling diodes
- Recommended snubber network :
- RC: 1 uF, 20 Ohms, (P R = 2W), Rp = 25 kOhms (P R = 20 W )
Semikron Standard Recovery Diodes, SKN320 Series
Semikron
SKN320/08
DIODE, M24, 800V, 320A, REV, M24X1.5 ; Package Type; Case E 16
Polarity; Anode Stud (Reverse)
Vrrm (volts); 800 Volts
IF (rms) Amps; 700 Amps
IF (avg) Amps; 320 Amps
Ifsm Amps; 9000 Amps
I2T@60Hz (A2Sec); 400000
I2T@50Hz (A2Sec); 400000
Vfm (volts); 1.35 Volts
Junction Temp.; 356 Degrees F
Mounting Force; 531.01 lbf-in
Stud Size; M24 x 1.50
Lead Type; Flexible
Lead Length FMS (inches); 9.06 Inches ;
SKN320/08
Specific References
- MPN
- SKN320/08
