LH1510

High Voltage Solid State Relay

3750 Vrms or 5300 Vrms I/O isolation

Current-limit protection built-in

Linear ac/dc operation

High-reability monolithic receptor

Extremely low leakage current (pA)

High contact off-impedance (G Ohms )

Low power consumtion ( 1 mW - 12mW)

Very low switch offset (typically 0.1 uV)

Logic compatible

Clean, bounce-free switching

Built-in 1 Form C break-before-make

High surge capability

Insensitive to dv/dt

Surface mountable

Compatible with UL 1459 and FCC 68.302

UL recognized

CSA certified

BABT certificate of recognition to BS6301

Applications

AC Switch

Telephone

Heater ControlLight Control

Switching Systems

Volmeters

Test Equipment

Modems

Programmable Controllers

Data Acquisition Systems

Security Equipment

Electric Meters

Ring Relay

Service Equipment

E & M Signaling

Multiplexers

Scanners

Motor Controls

Output Modules

Thermostats

Answering Machines

Battery Switch

Board Testers

Gas Pumps
