- Out-of-Stock
T500074005AQ
$47.25
No tax
T500074005AQ
Política de seguridad
(Our products have limited warranty, please check our terms)
Política de entrega
(Delivery 1-2 days for products in stock)
Features
- Phase Control SCR
- Center Fired, di/namic Gate
- All Diffused Design
- Low VTM
- Compression Bonded Encapsulation
- Low Thermal Impedance
- High Surge Current Capability
- Low Gate Current
Aplications
- Applications
- Phase Control
- Motor Control
- Power Supplies
Powerex Phase Control SCRs, T500 Series
Powerex
T500074005AQ
SCR, TO-94, 700V, 40A ; Package Style; TO-94
Vrrm (volts); 700 Volts
Vdrm (volts); 700 Volts
It (rms) Amps; 63 Amps
It (avg) Amps; 40 Amps
Itsm Amps; 1200 Amps
dv/dt (V/microseconds); 300
I2T@60Hz (A2Sec); 6000
Vtm (volts); 3.7 Volts
tq (microseconds); 100 MicroSeconds
Irrm Peak (mA); 10 MilliAmps
Idrm Peak (mA); 10 MilliAmps
Igt (mA); 100 MilliAmps
Vgt (volts); 3 Volts
Stud Size; 1/2-20 UNF-2A
Lead Length FMS (inches); 7.1 Inches
Junction Temp.; -40~257 Degrees F
Mounting Force; 130 lbf-inches
T500074005AQ
Specific References
- MPN
- T500074005AQ
