MIC4452

12A-Peak Low-Side MOSFET Driver

BiCMOS/DMOS Construction

Latch-Up Proof : Fully Isolated Process is Inherently

Immune to Any Latch-up

Input Will Withstand Negative Swing of Up to 5V

Matched Rise and Fall Times u00e2u0080u00a6u00e2u0080u00a6u00e2u0080u00a6u00e2u0080u00a6u00e2u0080u00a6u00e2u0080u00a6u00e2u0080u00a6u00e2u0080u00a6u00e2u0080u00a6 25ns

High Peak Output Current .................... 12A Peak

Wide Operating Range ...................... 4.5V to 18V

High Capacitive Load Drive ..................... 62000pF

Low Delay Time .................................... 30ns Typ.

Logic High Input for Any Voltage from 2.4V to VS

Low Supply Current .... 450uA with logic 1 Input

Low Output Impedance ...................... 1.0 Ohms

Output Voltage Swing to Within 25mV of GND or VS

Low Equivalent Input Capacitance (typ) ........ 7pF
