Features
- Fast Recovery Rectifier
- Fast Recovery Times
- Soft Recovery Characteristics
- Stu00c3u00a1ndar and Reverse Polarities
- Flag Leads and Stud Top Terminals Available
- High Surge Current Ratings
- High Rated Blocking Voltages
- Special Electrical Selection for Parallel and Series Operation
- Glazed Ceramic Seal Gives High Voltage Creepage and Strike Paths
Aplications
- Applications
- Inverters
- Choppers
- Transmitters
- Free Wheeling Diode
Powerex Fast Recovery Diodes, R502/503 Series
Powerex
R5020818FSWA
Diode,DO-8,800V,175A,FWD,1500nS ; Package Type; DO-205AA (DO-8)
Polarity; Cathode Stud (Forward)
Vrrm (volts); 800 Volts
IF (rms) Amps; 275 Amps
IF (avg) Amps; 175 Amps
Ifsm Amps; 3500 Amps
I2T@60Hz (A2Sec); 51000
Vfm (volts); 1.65 Volts
trr (nanoseconds); 1500 NanoSeconds
Junction Temp.; 302 Degrees F
Mounting Force; 120 lbf-inches
Stud Size; 3/8-24 UNF-2A
Lead Type; Flexible
Lead Length FMS (inches); 4.48 Inches ;
R5020818FSWA
Specific References
- MPN
- R5020818FSWA
