- On request
R5021418FSWA
$51.98
No tax
R5021418FSWA
Política de seguridad
(Our products have limited warranty, please check our terms)
Política de entrega
(Delivery 1-2 days for products in stock)
Features
Fast Recovery Rectifier
Fast Recovery Times
Soft Recovery Characteristics
Flag Lead and Stud Top Terminals
Available
High Surge Current Ratings
High Rated Blocking Voltages
Special Electrical Selection for Parallel
and Series Operation
Glazed Ceramic Seal Gives
High Voltage Creepage and Strike Paths
Aplications
Applications
Inverters
Choppers
Transmitters
Free Wheeling Diode
Powerex Fast Recovery Diodes, R502/503 Series
Powerex
R5021418FSWA
Diode,DO-8,1400V,175A,FWD,1500nS ; Package Type; DO-205AA (DO-8)
Polarity; Cathode Stud (Forward)
Vrrm (volts); 1400 Volts
IF (rms) Amps; 275 Amps
IF (avg) Amps; 175 Amps
Ifsm Amps; 3500 Amps
I2T@60Hz (A2Sec); 51000
Vfm (volts); 1.65 Volts
trr (nanoseconds); 1500 NanoSeconds
Junction Temp.; 302 Degrees F
Mounting Force; 120 lbf-inches
Stud Size; 3/8-24 UNF-2A
Lead Type; Flexible
Lead Length FMS (inches); 4.48 Inches ;
R5021418FSWA
Specific References
- MPN
- R5021418FSWA
