SD600N20PC
$190.58
No tax
SD600N20PC
Política de seguridad
(Our products have limited warranty, please check our terms)
Política de entrega
(Delivery 1-2 days for products in stock)
Features
- Stu00c3u00a1ndar Recovery Diode
- Wide current range
- High voltage rating up to 3200 V
- High surge current capabilities
- Stud cathode and stud anode version
- Stu00c3u00a1ndar JEDEC types
Aplications
- Applications
- Converters
- Power supplies
- Machine tool controls
- High power drives
- Medium traction applications
Vishay Standard Recovery Diodes, SD600 Series
Vishay
SD600N20PC
DIODE, DO-205AD, 2000V, 600A, FWD STD ; Package Type; DO-205AD
Polarity; Cathode Stud (Forward)
Vrrm (volts); 2000 Volts
IF (rms) Amps; 940 Amps
IF (avg) Amps; 600 Amps
Ifsm Amps; 92 Amps
I2T@60Hz (A2Sec); 772000
I2T@50Hz (A2Sec); 845000
Vfm (volts); 1.31 Volts
Junction Temp.; -40~356 Degrees F
Mounting Force; 442 lbf-inches
Stud Size; 3/4-16 UNF-2A
Lead Type; Flexible
Lead Length FMS (inches); 10.04 Inches
RoHS Compliant; Yes ;
SD600N20PC
Specific References
- MPN
- SD600N20PC
