PM50CLA120
196,88 $
Aucune taxe
PM50CLA120
Política de seguridad
(Los productos cuentan con garantía limitada, por favor revisa nuestras condiciones)
Política de entrega
(Envíos de 1-2 días hábiles para productos de stock)
Features
- INTELLIGENT POWER MODULE
- Adopting new 5th generation IGBT (CSTBT) chip, which performance is improved by 1um fine rule process
- For example, typical VDO(sat)=1.9V Tj=125 C
- I adopt the over-temperature conservation by Tj detection of CSTBT chip, and error outputs is possible from all each conservation upper and lower arm of IPM
- c) New small packaeg
- Reduce thepackage size by 10%, thickness by 22% from S-DASH series
- 3 0/ 50A, 1200V Current-sense IGBT type inverter
- Monolithic gate drive & protection logic
- Detection, protection & status indication circuits for, short-circuit, over-temperature& under-voltage (P-Fo available from upper arm devices)
- Acoustic noise-less 5.5kW/7.5kW class inverter application
- UL Recognized Yellow Card No. E80276(n) File No. E80271
Aplications
- Applications
- General purpose inverter
- servo drives
- motor controls
Powerex Intelligent Power Module (IPM)
Powerex
PM50CLA120
IPM, SIX-PACK, 1200V, 50A
PM50CLA120
Références spécifiques
- MPN
- PM50CLA120
