C155D
search
  • C155D
  • C155D

C155D

91,88 $
Aucune taxe

Inicio

Última actualización

DatasheetC155D

110Arms/400V/1U

No Identificado

Delivery time :

Quantité
On request

  Política de seguridad

(Los productos cuentan con garantía limitada, por favor revisa nuestras condiciones)

  Shipping and Returns

All products come with a warranty against manufacturing defects.

  Trademark Disclaimer

All trademarks, logos, and part numbers are the property of their respective owners click for more

Features

Silicon Controlled Rectifier

Aplications

Semiconductors High Power Equipment Repair

Powerex Inverter SCRs, C155 Series

Powerex

C155D

SCR, TO-94, 400V, 110A, TQ=20 ; Package Style; TO-94

Vrrm (volts); 400 Volts

Vdrm (volts); 400 Volts

It (rms) Amps; 110 Amps

dv/dt (V/microseconds); 300

(A2Sec); 13500

(A2Sec); 9500

Vtm (volts); 3 Volts

tq (microseconds); 20 MicroSeconds

Irrm Peak (mA); 12 MilliAmps

Idrm Peak (mA); 12 MilliAmps

Igt (mA); 200 MilliAmps

Vgt (volts); 5 Volts

Stud Size; 1/2-20 UNF-2A

Lead Length FMS (inches); 6.39 Inches

Junction Temp.; 257 Degrees F

Mounting Force; 17 Nm

C155D

Références spécifiques

MPN
C155D
