ST1280C04K0
242,55 $
Aucune taxe
SCR - THYRISTOR CONTROL DE FASE
Última actualización
ST1280C04K02310A/400V/1U
No Identificado
Delivery time :
Política de seguridad
(Los productos cuentan con garantía limitada, por favor revisa nuestras condiciones)
Shipping and Returns
All products come with a warranty against manufacturing defects.
Trademark Disclaimer
All trademarks, logos, and part numbers are the property of their respective owners click for more
Features
Phase Control Thyristor
Center amplifying gate
Metal case with ceramic insulator
International stu00c3u00a1ndar case A-24 (K-PUK)
High profile hockey PUK
Lead (Pb)-free
Aplications
Applications
DC motor controls
Controlled DC power supplies
AC controllers
Vishay Phase Control SCRs, ST Series
Vishay
ST1280C04K0
SCR, TO-200AD, 400V, 2310A ; Package Style; TO-200AD
Vrrm (volts); 400 Volts
Vdrm (volts); 400 Volts
It (rms) Amps; 4150 Amps
It (avg) Amps; 2310 Amps
Itsm Amps; 44500 Amps
di/dt (A/microseconds); 1000
dv/dt (V/microseconds); 500
I2T@60Hz (A2Sec); 8240000
I2T@50Hz (A2Sec); 9027000
Vtm (volts); 1.44 Volts
tq (microseconds); 200 MicroSeconds
Irrm Peak (mA); 100 MilliAmps
Idrm Peak (mA); 100 MilliAmps
Igt (mA); 200 MilliAmps
Vgt (volts); 3 Volts
Puck Size (h x dia.) in.; 1x3
Junction Temp.; -40~257 Degrees F
Mounting Force; 32 Kn
ST1280C04K0
Références spécifiques
- MPN
- ST1280C04K0
