- Rupture de stock
MC5514
91,88 $
Aucune taxe
MC5514
Política de seguridad
(Los productos cuentan con garantía limitada, por favor revisa nuestras condiciones)
Política de entrega
(Envíos de 1-2 días hábiles para productos de stock)
Features
- INTELLIGENT POWER MODULE
- a) Adopting new 5th generation IGBT (CSTBT) chip, which performance is improved by 1um fine rule prodess.
- For example, typical VCE(sat) = 1.8 V @ Tj = 125 C
- b) I adopt the over-temperature conservation by Tj detection of CSTBT chip, and error output is possible from all each conservation upper and lower arm of IPM.
- 3 phase 450 A, 600 V Current-sense IGBT type inverter
- Monolithic gate drive & protection logic
- Detection, protection & status indication circuits for, short-circuit, over-temperature & under-voltage (Fo available from all arm devices)
- Acoustic noise-less 37kW class inverter applications
- UL Recognized Yellow Card No. E80276(N)
- File No. E80271
Aplications
- Applications
- General purpose inverter
- servo drives
- motor controls
MC5514
Références spécifiques
- MPN
- MC5514
