0287030
4,60 $
Nessuna tassa
10 Articoli
0287030
Política de seguridad
(Los productos cuentan con garantía limitada, por favor revisa nuestras condiciones)
Política de entrega
(Envíos de 1-2 días hábiles para productos de stock)
Features
- ATOF automotive blade fuses were developed to take the place of obsolete ATO Series 257 fuses. Automakers consider ATOF fuses standard equipment for protecting low-voltage circuits.
- Color coding indicates amperage rating
- Shunt version available (Tin plated only )
- See-through housings make it easier to see when fuses blow
- High-contrast ampere stamps on housings aid identification
- Checkpoints on top make it possible to measure resistance without removing the fuse
- Voltage Rating: 32 V DC
- Interrupting Rating: 1000 A @ 32 V DC
- Recommended Environmental
- Temperature:
- –40 oC to +125 oC (ATOF)
- –40 oC to +105 oC (ATOF Shunt)
- Terminals Material: Tin- or silver-plated*
- Housing Material: PA66
- (UL 94 Flammability rating of V-2)
- Typical Weight Per Fuse: 1.4 g
- Comply With: SAE J1284 and ISO 8820-3
- UL Listed: File AU1410
- CSA Certified: File No. 29862
Aplications
- Fusibles para automóviles ATOF 32V 30A Low-Current Nylon
0287030
Riferimenti Specifici
- MPN
- 0287030
