PM50RLB060
110,46 $
Nessuna tassa
PM50RLB060
Política de seguridad
(Los productos cuentan con garantía limitada, por favor revisa nuestras condiciones)
Política de entrega
(Envíos de 1-2 días hábiles para productos de stock)
Features
- INTELLIGENT POWER MODULE
- a) Adopting new 5th generation IGBT (CSTBT) chp,
- which performance is improved by 1um fine
- rule process.
- For example, typical VCE(sat)=1.5V @ Tj125u00c2u00b0C
- b ) I adopt the over-temperature conservation by
- Tj detection of CSTBT chip, and error output is
- possible from all each conservation upper and lower
- arm of IPM
- c ) New small package
- Reduce the package size by 32%, thickness by 22%
- from S-DASH series
- d ) Current rating of brake part increased
- 60% for the current rating of inverter part
- 3 o/ 50A, 600V Current-sense IGBT type inverter
- 30A, 600V Current-sense regenerative brake IGBT
- Monolithic gate drive & protection logic
- Detection, protection & status indication circuits for,
- short-circuit, over-temperature & under-voltage (
- P-Fo available from upper arm devices)
- Acoustic noise less 3.7kW class inverter application
Aplications
- Applications
- General purpose inverter
- servo drives
- motor controls
Powerex IPMs, Intellimod L Series
Powerex
PM50RLB060
IPM, 7-PACK, 600V, 50A ; Ic; 50 Amps
Vces; 600 Volts
Circuit Configuration; Three Phase Inverter with Brake ;
PM50RLB060
Riferimenti Specifici
- MPN
- PM50RLB060
