SKIM500GD128DM
search
  • SKIM500GD128DM

SKIM500GD128DM

918,75 $
Nessuna tassa

MODULOS IGBT

Última actualización

DatasheetSKIM500GD128DM

340A/1200V/6U

No identificado

Delivery time :

Quantità
Non disponibile

  Política de seguridad

(Los productos cuentan con garantía limitada, por favor revisa nuestras condiciones)

  Política de entrega

(Envíos de 1-2 días hábiles para productos de stock)

Features

  • IGBT MODULE
  • N channel, homogeneous planar IGBT
  • Silicon structure with n + buffer layer in
  • SPT (soft punch through ) technology
  • Low inductance case
  • Fast & soft inverse CAL diodes
  • Isolated by AIN DCB (Direct Copper Bonded)
  • ceramic plate
  • Pressure contact technology for thermal contacts
  • Spring contact system to attach driver PCB to the control terminals
  • Integrated temperature sensor

Aplications

  • Applications
  • Switched mode power supplies
  • Three phase inverters for AC
  • motor speed control
  • Switching (not for linear use)

Semikron IGBTs

Semikron

SKIM500GD128DM

IGBT,Six-Pack,1200V,500A ; Type; Six-Pack

Vces; 1200 Volts DC

Ic; 325 Amps

Vges +/-; 20

Ices Max; 0.3 MilliAmps

Vge(th) Min/Max; 4.45~6.55 Volts

Vce(sat) Max; 2.35 Volts

Height (mm); 34.5

Width (mm); 184.5

Depth (mm); 106.5

RoHS; Yes ;
