SKM200GAR123D
138,00 $
Nessuna tassa
MODULOS IGBT
Última actualización
SKM200GAR123D200A/1200V/1U
SEMIKRON
Delivery time : 1-2 semanas.
Política de seguridad
(Los productos cuentan con garantía limitada, por favor revisa nuestras condiciones)
Política de entrega
(Envíos de 1-2 días hábiles para productos de stock)
Features
TRENCH IGBT MODULE
MOS input (voltage controlled)
N channel, homogeneous Si
Low inductance case
Very low tail current with low temperature dependence
High short circuit capability, self limiting to 6 x Icnom
Latch-up free
Fast & soft inverse CAL diodes
DCB Direct Copper Bonding Technology
Large clearance (13 mm) and creepage distances (20 mm)
Aplications
Applications
Switching (not for linear use)
Semikron IGBTs
Semikron
SKM200GAR123D
IGBT 200A 1200V HIGH CHOPPER ; Type; Single
Vces; 1200 Volts DC
Ic; 180 Amps
Vges +/-; 20
Ices Max; 0.3 MilliAmps
Vge(th) Min/Max; 4.5~6.5 Volts
Vce(sat) Max; 3 Volts
Height (mm); 30.5
Width (mm); 106.4
Depth (mm); 61.4
RoHS; Yes ;
