SKN100/12
31,50 $
Nessuna tassa
RECTIFICADORES
Última actualización
SKN100/12100A/1200V/1U
No Identificado
Delivery time :
Alternativas del producto : SKN130/18
Política de seguridad
(Los productos cuentan con garantía limitada, por favor revisa nuestras condiciones)
Política de entrega
(Envíos de 1-2 días hábiles para productos de stock)
Features
Rectifier Diode
Reverse voltage up to 1800 V
Hermetic metal cases with glass insulators
Threaded studs ISO M12 , M16 x 1.5
SKN : anode to stud
SKR : cathode to stud
Aplications
Applications
All-purpose mean power rectifier
diodes
Cooling via heatsinks
Non-controllable and
half-controllable rectifiers
Free-wheeling diodes
Recommended snubber network :
RC: 0.25 uF, 50 Ohms, (P R = 2W)
Rp = 50kOhms (P R = 20 W )
Semikron Standard Recovery Diodes, SKN100 Series
Semikron
SKN100/12
DIODE, M12, 1200V, 100A, REV, STD, M12X1.75 ; Package Type; DO-205AC (DO-30)
Polarity; Anode Stud (Reverse)
Vrrm (volts); 1200 Volts
IF (rms) Amps; 200 Amps
IF (avg) Amps; 100 Amps
Ifsm Amps; 1750 Amps
I2T@60Hz (A2Sec); 15000
I2T@50Hz (A2Sec); 15000
Vfm (volts); 1.55 Volts
Junction Temp.; 356 Degrees F
Mounting Force; 88.51 lbf-in
Stud Size; M12 x 1.75
Lead Type; Flexible
Lead Length FMS (inches); 6.5 Inches ;
SKN100/12
Riferimenti Specifici
- MPN
- SKN100/12
