SKN4000/02
381,15 $
Nessuna tassa
SKN4000/02
Política de seguridad
(Los productos cuentan con garantía limitada, por favor revisa nuestras condiciones)
Política de entrega
(Envíos de 1-2 días hábiles para productos de stock)
Features
- Rectifier Diode
- Capsule type metal-ceramic package with precious metal pressure contacts
- Medium voltage, high current rectifier diodes with slim package for lowest themal resistance
- Low power dissipation
- Especially suited for water cooling
- Forward selections for paralleling
- available
Aplications
- Applications
- Welding
- Electroplating
Semikron Standard Recovery Diodes, SKN4000 Series
Semikron
SKN4000/02
DIODE, DO60/8, 200V, 3200A, STD ; Package Type; DO-200AB-3
Puck Size (h x dia.) in.; .31 x 2.36 inches
Vrrm (volts); 200 Volts
IF (rms) Amps; 6300 Amps
IF (avg) Amps; 4000 Amps
Ifsm Amps; 60000 Amps
I2T@60Hz (A2Sec); 18000000
I2T@50Hz (A2Sec); 18000000
Vfm (volts); 1.3 Volts
Junction Temp.; 356 Degrees F
Mounting Force; 24~30 kN ;
SKN4000/02
