• Non disponibile
SKR400/18
search
  • SKR400/18

SKR400/18

159,39 $
Nessuna tassa

RECTIFICADORES

Última actualización

DatasheetSKR400/18

400A/1800V/1U

No identificado

Delivery time :

Quantità
Non disponibile

  Política de seguridad

(Los productos cuentan con garantía limitada, por favor revisa nuestras condiciones)

  Política de entrega

(Envíos de 1-2 días hábiles para productos de stock)

Features

  • Rectifier Diode
  • Reverse voltage up to 1600 V
  • Hermetic metal cases with glass insulators
  • Threaded studs ISO M24 x 1.5
  • SKN : anode to stud
  • SKR : cathode to stud

Aplications

  • Applications
  • All-purpose mean power rectifier diodes
  • Cooling via heatsinks
  • Non-controllable and
  • half-controllable rectifiers
  • Free-wheeling diodes
  • Recommended snubber network :
  • RC: 1 uF, 20 Ohms, (P R = 2W), Rp = 25 kOhms (P R = 20 W )

Semikron Standard Recovery Diodes, SKN400 Series

Semikron

SKR400/18

DIODE,M24,1800V,400A,FWD,STD, M24x1.50 ; Package Type; Case E 17

Polarity; Cathode Stud (Forward)

Vrrm (volts); 1800 Volts

IF (rms) Amps; 700 Amps

IF (avg) Amps; 400 Amps

Ifsm Amps; 9000 Amps

I2T@60Hz (A2Sec); 400000

I2T@50Hz (A2Sec); 400000

Vfm (volts); 1.45 Volts

Junction Temp.; 320 Degrees F

Mounting Force; 531.04 lbf-in

Stud Size; M24 x 1.50

Lead Type; Flexible Insulated Black

Lead Length FMS (inches); 9.06 Inches ;

SKR400/18

Riferimenti Specifici

MPN
SKR400/18
