RV4NAYSD252A
96,60 $
Nessuna tassa
RESISTOR
Última actualización
RV4NAYSD252A2.5KOHM 2W 1 TURN
OHMITE
Delivery time : 1-2 semanas.
Política de seguridad
(Los productos cuentan con garantía limitada, por favor revisa nuestras condiciones)
Política de entrega
(Envíos de 1-2 días hábiles para productos de stock)
Features
- hot molded carbon element
- gold-plated terminals
- stainless-steel shaft and housing
- quality meeting or exceeding MIL-R-94 - QPL listed
- Resistance tolerance: ±10% or ±20%
- Power rating: 2 watts at 70°C derated to 0 watts at 120°C
- Insulation resistance:
- dry: 10K Meg?
- wet: 100K Meg?
- Dielectric strength: 900 V RMS at sea level
- Operating voltage: 500 V, subject to power rating
- Electrical Rotation: 285°
- Mechanical rotation: 314° with Switch 333°
- Operating torque: 1 oz/in to 6 oz/in
- Rotational life: 25,000 cycles
- Stop Torque: Max 8lb-in
- Locking Nut Torque: Max 10 lb-in
Aplications
- Precision series RV4 potentiometers are suitable for
- both military and commercial applications.
