- On request
SKT100/12E
45,05 $
Nessuna tassa
SCR - THYRISTOR CONTROL DE FASE
Última actualización
SKT100/12E100A/1200V/1U
No Identificado
Delivery time :
Alternativas del producto : SKT100/18E
Política de seguridad
(Los productos cuentan con garantía limitada, por favor revisa nuestras condiciones)
Política de entrega
(Envíos de 1-2 días hábiles para productos de stock)
Features
THYRISTOR
Hermetic metal cases with ceramic insulators
Threaded studs ISO M12 or UNF 1/2 - 20
Interchangeable with International stu00c3u00a1ndar cases
Aplications
Applications
DC motor control (e. g. for
machine tools)
Controlled rectifiers (e. g.
For battery charging)
AC controllers (e. g. for
temperature control)
Semikron Phase Control SCRs, SKT100 Series
Semikron
SKT100/12E
SCR, M12, 1200V, 100A, M12X1.75 METR ; Package Style; TO-94
Vrrm (volts); 1200 Volts
Vdrm (volts); 1200 Volts
It (rms) Amps; 175 Amps
It (avg) Amps; 100 Amps
Itsm Amps; 2000 Amps
di/dt (A/microseconds); 50
dv/dt (V/microseconds); 1000
I2T@50Hz (A2Sec); 20000
Vtm (volts); 1.75 Volts
tq (microseconds); 100 MicroSeconds
Irrm Peak (mA); 30 MilliAmps
Idrm Peak (mA); 30 MilliAmps
Igt (mA); 150 MilliAmps
Vgt (volts); 3 Volts
Stud Size; M12 x 1.75
Lead Length FMS (inches); 6.3 Inches
Junction Temp.; 266 Degrees F
Mounting Force; 141 lbf-inches
RoHS; Yes
Diag. No.; SEKG_SCR_DIAG_B5
SKT100/12E
Riferimenti Specifici
- MPN
- SKT100/12E
