T218N12TOF
search
  • T218N12TOF
  • T218N12TOF

T218N12TOF

90,09 $
Nessuna tassa

SCR - THYRISTOR CONTROL DE FASE

Última actualización

DatasheetT218N12TOF

218A/1200V/1U

No identificado

Delivery time :

Quantità
Non disponibile

  Política de seguridad

(Los productos cuentan con garantía limitada, por favor revisa nuestras condiciones)

  Política de entrega

(Envíos de 1-2 días hábiles para productos de stock)

Features

  • MEDIUM POWER PHASE CONTROL THYRISTOR MODULE
  • Electrically isolated base plate
  • Types up to 1600 VRRM
  • 3500 VRMS isolating voltage
  • Simplified mechanical designs, rapid assembly
  • High surge capability
  • Large creepage distances
  • UL E78996 approved RU

Aplications

  • Semiconductors High Power Equipment Repair

Infineon, Formerly Eupec Phase Control SCRs, T218N Series

Infineon, Formerly Eupec

T218N12TOF

SCR,TO41/14,1200V,218A ; Package Style; TO-200AB-1

Vrrm (volts); 1200 Volts

Vdrm (volts); 1200 Volts

It (rms) Amps; 400 Amps

It (avg) Amps; 218 Amps

Itsm Amps; 3800 Amps

di/dt (A/microseconds); 150

dv/dt (V/microseconds); 1000

I2T@50Hz (A2Sec); 72000

Vtm (volts); 2.2 Volts

tq (microseconds); 200 MicroSeconds

Irrm Peak (mA); 30 MilliAmps

Idrm Peak (mA); 30 MilliAmps

Igt (mA); 150 MilliAmps

Vgt (volts); 2 Volts

Puck Size (h x dia.) in.; .5x1.63

Junction Temp.; 257 Degrees F

Mounting Force; 5 kN

RoHS; Yes

Diag. No.; EUPC_SCR_DIAG_T41.14_23POLE

T218N12TOF
