Features
Phase Control SCR
Aplications
Semiconductors High Power Equipment Repair
Powerex Phase Control SCRs, 2N Series
Powerex
2N1800
SCR, TO-83, 600V, 70A ; Package Style; TO-83
Vrrm (volts); 600 Volts
Vdrm (volts); 600 Volts
It (rms) Amps; 110 Amps
It (avg) Amps; 70 Amps
Itsm Amps; 1000 Amps
dv/dt (V/microseconds); 300
(A2Sec); 4000
Vtm (volts); 2.3 Volts
tq (microseconds); 100 MicroSeconds
Irrm Peak (mA); 10 MilliAmps
Idrm Peak (mA); 10 MilliAmps
Igt (mA); 70 MilliAmps
Vgt (volts); 3 Volts
Stud Size; 1/2-20 UNF-2A
Lead Length FMS (inches); 7.04 Inches
Junction Temp.; -40~257 Degrees F
Mounting Force; 130 lbf-inches
2N1800
Riferimenti Specifici
- MPN
- 2N1800
