Features
Distributed Gate Thyristor
Aplications
Semiconductors High Power Equipment Repair
Westcode Semiconductors Inverter SCRs, R Series
Westcode Semiconductors
R1127NC36S
SCR,TO-200AD,3600V,2247A,TQ=160 ; Package Style; W11
Vrrm (volts); 3600 Volts
Vdrm (volts); 3600 Volts
It (rms) Amps; 2247 Amps
It (avg) Amps; 1127 Amps
Itsm Amps; 12800 Amps
di/dt (A/microseconds); 1000
dv/dt (V/microseconds); 200
I2T@60Hz (A2Sec); 819000
Vtm (volts); 2.42 Volts
tq (microseconds); 160 MicroSeconds
Irrm Peak (mA); 100 MilliAmps
Idrm Peak (mA); 100 MilliAmps
Igt (mA); 300 MilliAmps
Vgt (volts); 3 Volts
Puck Size (h x dia.) in.; 1.09 x 2.91 inches
Junction Temp.; 257 Degrees F
Mounting Force; 19~26 kN
RoHS; Yes ;
