Features
Distributed Gate Thyristor
Aplications
Semiconductors High Power Equipment Repair
Westcode Semiconductors Inverter SCRs, R1271NS Series
Westcode Semiconductors
R1271NS12C
SCR,TO-200AD,1200V,2599A,TQ=15 ; Vrrm (volts); 1200 Volts
Vdrm (volts); 1200 Volts
It (rms) Amps; 2599 Amps
It (avg) Amps; 1271 Amps
Itsm Amps; 18000 Amps
di/dt (A/microseconds); 1000
dv/dt (V/microseconds); 200
(A2Sec); 1620000
Vtm (volts); 2.02 Volts
tq (microseconds); 15 MicroSeconds
Irrm Peak (mA); 150 MilliAmps
Idrm Peak (mA); 150 MilliAmps
Igt (mA); 300 MilliAmps
Vgt (volts); 3 Volts
Puck Size (h x dia.) in.; 1.09 x 2.91 inches
Junction Temp.; 257 Degrees F
Mounting Force; 19~26 kN
