Features
High Frequency Inverter Thyristor
Aplications
Semiconductors High Power Equipment Repair
Westcode Semiconductors Inverter SCRs, R216CH Series
Westcode Semiconductors
R216CH12FHO
SCR,TO-200AB-1,1200V,1125A,TQ=30 ; Package Style; TO-200AB
Vrrm (volts); 1200 Volts
Vdrm (volts); 1200 Volts
It (rms) Amps; 1125 Amps
It (avg) Amps; 560 Amps
Itsm Amps; 6300 Amps
dv/dt (V/microseconds); 200
I2T@60Hz (A2Sec); 240000
Vtm (volts); 1.85 Volts
tq (microseconds); 30 MicroSeconds
Irrm Peak (mA); 60 MilliAmps
Idrm Peak (mA); 60 MilliAmps
Igt (mA); 200 MilliAmps
Vgt (volts); 3 Volts
Puck Size (h x dia.) in.; .59 x 1.65 inches
Junction Temp.; 257 Degrees F
R216CH12FHO
