R5020210RSWA
62,37 $
Nessuna tassa
R5020210RSWA
Política de seguridad
(Los productos cuentan con garantía limitada, por favor revisa nuestras condiciones)
Política de entrega
(Envíos de 1-2 días hábiles para productos de stock)
Features
Fast Recovery Rectifier
Fast Recovery Times
Soft Recovery Characteristics
Flag Lead and Stud Top Terminals
Available
High Surge Current Ratings
High Rated Blocking Voltages
Special Electrical Selection for Parallel
and Series Operation
Glazed Ceramic Seal Gives
High Voltage Creepage and Strike Paths
Aplications
Applications
Inverters
Choppers
Transmitters
Free Wheeling Diode
Powerex Fast Recovery Diodes, R502/503 Series
Powerex
R5020210RSWA
Diode,DO-8,200V,100A,FWD,300nS ; Package Type; DO-205AA (DO-8)
Polarity; Cathode Stud (Forward)
Vrrm (volts); 200 Volts
IF (rms) Amps; 150 Amps
IF (avg) Amps; 100 Amps
Ifsm Amps; 2200 Amps
I2T@60Hz (A2Sec); 20000
Vfm (volts); 4.5 Volts
trr (nanoseconds); 300 NanoSeconds
Junction Temp.; 302 Degrees F
Mounting Force; 120 lbf-inches
Stud Size; 3/8-24 UNF-2A
Lead Type; Flexible
Lead Length FMS (inches); 4.48 Inches ;
R5020210RSWA
Riferimenti Specifici
- MPN
- R5020210RSWA
