SK45UT16
78,75 $
Nessuna tassa
SK45UT16
Política de seguridad
(Los productos cuentan con garantía limitada, por favor revisa nuestras condiciones)
Política de entrega
(Envíos de 1-2 días hábiles para productos de stock)
Features
- Antiparallel Thyristor Module
- Compact Design
- One screw mounting
- Heat transfer and isolation through direct copper bonded alumimium oxide ceramic (DBC)
- Glass passived thyristor chips
- Up to 1600V reverse voltage
- UL recognized, file no. E 63 532
Aplications
- Applications
- Soft starters
- Ligh control (studios, theaters.. )
- Temperature control
Semikron Standard SCR Power Modules, SK Series
Semikron
SK45UT16
POWER MODULE ; It (RMS); 47 Amps
Vrrm; 1600 Volts
Circuit; Triple SCR AC Switch
Height (mm) Nominal; 16 MilliMeters
Width (mm) Nominal; 31 MilliMeters
Depth (mm) Nominal; 55 MilliMeters
Tq; 80 MicroSeconds
Igt; 100 MilliAmps
di/dt (Amps/MicroSec.); 50
dV/dt (Volts/MicroSec.); 1000
Package Type; SEMITOP3
Approvals; ULR ;
