ST083S10PFK0
55,44 $
Nessuna tassa
ST083S10PFK0
Política de seguridad
(Los productos cuentan con garantía limitada, por favor revisa nuestras condiciones)
Política de entrega
(Envíos de 1-2 días hábiles para productos de stock)
Features
- INVERTER GRADE THYRISTOR
- All diffused design
- Center amplifying gate
- Guaranteed high dv/dt
- Guaranteed high di/dt
- High surge current capability
- Low thermal impedance
- High speed performance
Aplications
- Applications
- Inverters
- Choppers
- Induction heating
- All types or force-commutated
- converters
Vishay Inverter SCRs, ST-S Series
Vishay
ST083S10PFK0
SCR,TO-94,1000V,135A,TQ=20 ; Package Style; TO-94
Vrrm (volts); 1000 Volts
Vdrm (volts); 1000 Volts
It (rms) Amps; 135 Amps
It (avg) Amps; 85 Amps
Itsm Amps; 2560 Amps
dv/dt (V/microseconds); 500
I2T@60Hz (A2Sec); 27000
Vtm (volts); 2.15 Volts
tq (microseconds); 20 MicroSeconds
Irrm Peak (mA); 30 MilliAmps
Idrm Peak (mA); 30 MilliAmps
Igt (mA); 200 MilliAmps
Vgt (volts); 3 Volts
Stud Size; 1/2-20 UNF-2A
Lead Length FMS (inches); 6.18 Inches
Junction Temp.; 257 Degrees F
Mounting Force; 15.5 Nm
ST083S10PFK0
