T720084504DN
search
  • T720084504DN

T720084504DN

138,60 $
Nessuna tassa

VARIOS

Última actualización

DatasheetT720084504DN

450A/800V/1U

No identificado

Delivery time :

Quantità
Non disponibile

  Política de seguridad

(Los productos cuentan con garantía limitada, por favor revisa nuestras condiciones)

  Política de entrega

(Envíos de 1-2 días hábiles para productos de stock)

Features

  • Phase Control SCR
  • Low On-State Voltage
  • High di/dt
  • High dv/dt
  • Hermetic Packaging
  • Excellent Surge and i2t Rating

Aplications

  • Applications
  • Power Supplies
  • Battery Chargers
  • Motor Control
  • VAR Generators

Powerex Phase Control SCRs, T720 Series

Powerex

T720084504DN

SCR, TO-200AC, 800V, 450A ; Package Style; TO-200AC

Vrrm (volts); 800 Volts

Vdrm (volts); 800 Volts

It (rms) Amps; 700 Amps

It (avg) Amps; 450 Amps

Itsm Amps; 8400 Amps

di/dt (A/microseconds); 150

dv/dt (V/microseconds); 300

(A2Sec); 295000

Vtm (volts); 1.6 Volts

tq (microseconds); 150 MicroSeconds

Irrm Peak (mA); 30 MilliAmps

Idrm Peak (mA); 30 MilliAmps

Igt (mA); 150 MilliAmps

Vgt (volts); 3 Volts

Puck Size (h x dia.) in.; 1x2.25

Junction Temp.; -40~257 Degrees F

Mounting Force; 10 Kn

T720084504DN

Riferimenti Specifici

MPN
T720084504DN
