- On request
SKMD105F12
$ 65,63
Sem imposto
MODULOS DIODO DIODO
Última actualización
SKMD105F12105A/1200V/2U
No Identificado
Delivery time :
Política de seguridad
(Los productos cuentan con garantía limitada, por favor revisa nuestras condiciones)
Shipping and Returns
All products come with a warranty against manufacturing defects.
Trademark Disclaimer
All trademarks, logos, and part numbers are the property of their respective owners click for more
Features
Fast Diode MODULE
Heat transfer through ceramic isolated
metal baseplate
Hard soldered joints for high reliability
SKMD common cathode
UL recognized, file no. E 63 532
Aplications
Applications
Self-commutated inverters
DC choppers
AC motor speed control
Inductive heating
Uninterruptible power supplies
Electronic welders
General power switching applications
Semikron Fast Recovery Diode Power Modules, SKMD Series
Semikron
SKMD105F12
POWER MODULE 105A 1200V 200NS ; It (avg); 102 Amps
Vrrm; 1200 Volts
Circuit; Diode Doubler Common Cathode
Height (mm) Nominal; 30 MilliMeters
Width (mm) Nominal; 20 MilliMeters
Depth (mm) Nominal; 93 MilliMeters
Trr; 1890 NanoSeconds
Package Type; SEMIPACK1
Mounting Centers; 80 MilliMeters
Approvals; ULR ;
SKMD105F12
Referências específicas
- MPN
- SKMD105F12
