- Esgotado
SKM75GD123D
$ 197,25
Sem imposto
SKM75GD123D
Política de seguridad
(Los productos cuentan con garantía limitada, por favor revisa nuestras condiciones)
Política de entrega
(Envíos de 1-2 días hábiles para productos de stock)
Features
- IGBT MODULE
- MOS input (voltage controlled)
- N channel, homogeneous Si
- Low inductance case
- Very low tail current with low temperature dependence
- High short circuit capability, self limiting to 6 Icnom
- Latch-up free
- Fast & soft inverse CAL diodes
- Isolated copper baseplate using DCB Direct Copper Bonding Technology
- Large clearance ( 9 mm ) and creepage distances ( 13 mm )
Aplications
- Applications
- Switched mode power suppliesDC servo and robot drives
- Three phase inverters for AC motor speed control
- Switching (not for linear use)
Semikron IGBTs
Semikron
SKM75GD123D
IGBT 75A 1200V 6-PACK ; Type; Six-Pack
Vces; 1200 Volts DC
Ic; 50 Amps
Vges +/-; 20
Ices Max; 1.2 MilliAmps
Vge(th) Min/Max; 4.5~6.5 Volts
Vce(sat) Max; 3 Volts
Height (mm); 22
Width (mm); 105
Depth (mm); 45
RoHS; Yes ;
SKM75GD123D
Referências específicas
- MPN
- SKM75GD123D
