Features
General Purpose Rectifier
Stu00c3u00a1ndar and Reverse Polarities
Flag Lead and Stud Top Terminals Available (R780)
Flat Base, Flange Mounted Design Available
High Surge Current Ratings
High Rated Blocking Voltages
Electrical Selection for Parallel and Series Operation
High Voltage Creepage and Strike Paths
Compression Bonded Encapsulation
Aplications
Applications
Welders
Battery Charges
Electromechanical Refining
Metal Reduction
General Industrial High Current Rectification
Powerex Standard Recovery Diodes, R701 Series
Powerex
R7011205XXUA
DIODE, DO-205AD, 1200V, 550A, REV STD ; Package Type; DO-205AD
Polarity; Anode Stud (Reverse)
Vrrm (volts); 1200 Volts
IF (rms) Amps; 865 Amps
IF (avg) Amps; 550 Amps
Ifsm Amps; 10000 Amps
I2T@60Hz (A2Sec); 416500
Vfm (volts); 1.2 Volts
Junction Temp.; -65~302 Degrees F
Mounting Force; 360 in-lb
Stud Size; 3/4-16 UNF-2A
Lead Type; Flexible
Lead Length FMS (inches); 9.66 Inches
RoHS Compliant; Yes ;
