SKN60F17
$ 20,79
Sem imposto
SKN60F17
Política de seguridad
(Los productos cuentan con garantía limitada, por favor revisa nuestras condiciones)
Shipping and Returns
All products come with a warranty against manufacturing defects.
Trademark Disclaimer
All trademarks, logos, and part numbers are the property of their respective owners click for more
Features
Fast Recovery Rectifier Diode
Small recovered charge
Soft recovery
Up to 1500 V reverse voltage
Hermetic metal case with glass insulator
Threaded studs ISO M6 and M8
SKN : anode to stud
SKR : cathode to stud
Aplications
Applications
Inverse diodes for power transistors, GTO thyristores, asymmetric thyristor
SMPS, inverters, choppers
A.C. motor control,uninterruptible power supplies (UPS)
Semikron Fast Recovery Diodes, SKNR60F Series
Semikron
SKN60F17
Diode,M6,1700V,75A,REV,2100nS, M6 x 1.00 Metric Stud ; Package Type; DO-203AB (DO-5)
Polarity; Anode Stud (Reverse)
Vrrm (volts); 1700 Volts
IF (avg) Amps; 60 Amps
Ifsm Amps; 1400 Amps
I2T@60Hz (A2Sec); 9800
I2T@50Hz (A2Sec); 7200
Vfm (volts); 1.75 Volts
trr (nanoseconds); 2100 NanoSeconds
Junction Temp.; -40~302 Degrees F
Mounting Force; 2.5 Nm
Stud Size; M6 x 1.00
Lead Type; Lug
Lead Length FMS (inches); 0.8071 Inches ;
SKN60F17
Referências específicas
- MPN
- SKN60F17
