SKT250/12E

$ 125,90
Sem imposto

MODULO DE POTENCIA MOSFET

Última actualización

DatasheetSKT250/12E

250A/1200V/1U

No identificado

Quantidade
Esgotado

  Política de seguridad

(Los productos cuentan con garantía limitada, por favor revisa nuestras condiciones)

  Política de entrega

(Envíos de 1-2 días hábiles para productos de stock)

Features

  • Line THYRISTOR
  • Hermetic metal cases with ceramic insulators
  • Theaded stud ISO M24 x 1.5
  • High i2t and ITSM values for easy fusing
  • International stu00c3u00a1ndar cases

Aplications

  • Applications
  • DC motor control (e. g. for
  • machine tools)
  • Controlled rectifiers (e. g.
  • For battery charging)
  • AC controllers (e. g. for
  • temperature control)
  • Recommended snubber network e. g. for VRMS < 400 V : R = 33 Ohms/32W, C = 0.47 uF

Semikron Phase Control SCRs, SKT250 Series

Semikron

SKT250/12E

SCR 250A 1200V M24 X 1.50 METRIC ; Package Style; TO-118

Vrrm (volts); 1200 Volts

Vdrm (volts); 1200 Volts

It (rms) Amps; 450 Amps

It (avg) Amps; 250 Amps

Itsm Amps; 7000 Amps

di/dt (A/microseconds); 100

dv/dt (V/microseconds); 1000

I2T@50Hz (A2Sec); 245000

Vtm (volts); 1.65 Volts

tq (microseconds); 150 MicroSeconds

Irrm Peak (mA); 50 MilliAmps

Idrm Peak (mA); 50 MilliAmps

Igt (mA); 200 MilliAmps

Vgt (volts); 3 Volts

Stud Size; M24 x 1.50

Lead Length FMS (inches); 9.05 Inches

Junction Temp.; 266 Degrees F

Mounting Force; 531 lbf-inches

RoHS; Yes

Diag. No.; SEKG_SCR_DIAG_B7

SKT250/12E

Referências específicas

MPN
SKT250/12E
