- On request
C150N
$ 55,44
Sem imposto
C150N
Política de seguridad
(Los productos cuentan con garantía limitada, por favor revisa nuestras condiciones)
Shipping and Returns
All products come with a warranty against manufacturing defects.
Trademark Disclaimer
All trademarks, logos, and part numbers are the property of their respective owners click for more
Features
Phase Control SCR
Aplications
Semiconductors High Power Equipment Repair
Powerex Phase Control SCRs, C150 Series
Powerex
C150N
SCR, TO-94, 800V, 70A ; Package Style; TO-94
Vrrm (volts); 800 Volts
Vdrm (volts); 800 Volts
It (rms) Amps; 100 Amps
It (avg) Amps; 70 Amps
Itsm Amps; 1500 Amps
di/dt (A/microseconds); 500
dv/dt (V/microseconds); 200
I2T@60Hz (A2Sec); 9340
Vtm (volts); 2.6 Volts
Irrm Peak (mA); 10 MilliAmps
Idrm Peak (mA); 10 MilliAmps
Igt (mA); 200 MilliAmps
Vgt (volts); 3 Volts
Stud Size; 1/2-20 UNF-2A
Lead Length FMS (inches); 7 Inches
Junction Temp.; -40~257 Degrees F
Mounting Force; 150 lbf-inches
C150N
Referências específicas
- MPN
- C150N
