4422CN
$ 13,13
Sem imposto
4422CN
Política de seguridad
(Los productos cuentan con garantía limitada, por favor revisa nuestras condiciones)
Política de entrega
(Envíos de 1-2 días hábiles para productos de stock)
Features
- 9A-Peak Low-Side MOSFET Driver
- Fearures
- BiCMOS/DMOS Construction
- Latch-Up Proof : Fully Isolated Process in
- Inherently Immune to Any Latch-up
- Input Will Withstand Negative Swing of
- Up to 5 V
- Matched Rise and Fall Times u00e2u0080u00a6.. 25ns
- High Peak Output Current ..... 9A Peak
- Wide Operating Range ...... 4.5V to 18V
- High Capacitive Load Drive .....47000pF
- Low Delay Time .................... 30ns Typ.
- Logic High Input for Any Voltage from
- 2.4V to VS
- Low Equivalent Input Capacitance (typ)
- ... 7pF
- Low Supply Current .. 450uA With Logic 1 Input
- Low Output Impedance ............ 1.5 Ohms
- Output Voltage Swing to Within 25mV of
- GND or VS
Aplications
- Applications
- Switch Mode Power Supplies
- Motor Control
- Pulse Transformer Drive
- Class-D Switching Amplifiers
- Line Drivers
- Driving MOSFET or IGBT Parallel
- Chip Modules
- Local Power ON/OFF Switch
- Pulse Generators
4422CN
Referências específicas
- MPN
- 4422CN
